세부사항

내용

Display

Triple display, 4 digit LCD reading

Wind pressure

0 ~ 9.999 N/㎡/ 10.00 ~ 99.99N/㎡/ 100.0 ~ 535.0N/㎡

Accuracy: ±2%rdg ±10dgts

Air velocity

Range: 0.5 ~ 30㎧/ Resolution: 0.01㎧/ Accuracy: ±2%rdg ±0.3㎧

Range:1.0 ~ 58.3 knots / Resolution: 0.1 knots / Accuracy: ±2%rdg

±0.6 knots

Range:99 ~ 5906 ft/min / Resolution: 1 ft/min / Accuracy: ±2%rdg

±59 ft/min

Air Flow

Range: 0 ~ 999.9㎥/s / Resolution: 0.01㎥/s /

Range: 0 ~ 9999 ft3/min / Resolution: 1 ft3/min

Range: 0 ~ 9999 l/s / Resolution: 1 l/s

Accuracy: Accuracy is function of velocity and duct size.

Wind temperature

Range: -20 ~ 85℃/ Resolution: 0.1℃/ Accuracy: ±1℃(25℃)

±2℃(-20 ~ 85℃)

Atmospheric pressure

Range: 10 ~ 2000 hPa / Resolution: 1 hPa / Accuracy: ±2%Pa (at 25℃)

±4%Pa (-20℃to 85℃)

Range：0.15 ~ 29 PSi / Resolution: 0.01 PSi /

Accuracy:±0.03% PSi (at 20℃), ±0.06% PSi (-20℃to 85℃)

Warm up time

< 1 minute

Response time

Velocity: < 2 seconds

Humidity: 63% < 10s (from 33% ~ 75%RH)

Temperature: 63% < 10s (from 15℃~ 45℃)

Sampling Rate

Two times per second

사용 온도

0℃~ 50℃

보관온도

-20℃~ 50℃

전원/배터리 수명

1pcs 9V배터리/약35시간

크기/무게

290(L)X113(W)X61(H)mm /약288g

악세사리

사용설명서, 배터리, Carrying Case
