세부사항

내용

Hardnee Scales

HV, HRC, HRB, HRA, HS, HL, HB

Measurement Range

HV(50-1700), HL(170-960),HRC(20-70), HRB(13-100),

HRA(60-85.38), HS(26.4-99.5), HB(30-651). HRE(20-70),

HRF(60-100)

Resolution

1HV, 0.1HRC

Accuracy

±4%H+10HV, ±2.5HRC(Probe fixture stand test,

H as the standard value)

Repeatability

±3%H+8HV, 2HRC(Probe fixture stand test,

H as the standard value)

Test Force

20N

Dispaly

240*240 dot matrix IPS

Power Supply

Rechargeble lithium battery 3.7V@1000mAh,

full charge for over 5000 continuous measurement

Charging Port

USB(Type-C)

크기(Size)/ 무게(Weight)

185*43*45mm / 245g

사용온도

-10 ~ 50℃, 0~85%RH(no condensation)

Supply Voltage

DC 5V

기본 액세서리

본체, 매뉴얼, Standard Hardness Block, USB Data Cable

Calibration Report,

옵션 액세서리

초음파경도계용 Stand
